Underwater 360deg Rotating Camera System

Variant Description: CAMERA HEAD

1. Camera size: Φ50mm x 153mm

2. Camera chip Aptina0130: 1/3 CMOS, 1.3MP 960P DSP: Nextchip2431

3. Camera Lens 5G+IR650, M8

4.Sensor: 1/3 inch HD CMOS 1.3MP pixel

Features & Compatibility

5. Sapphire lens protection glass

6. Waterproof level: IP68 10bars

7. Tilt angle: tilt 180º rotation, pan 360° infinite loop

8. Camera angle: 120°

9. Probe reset automatically

10. 6 high-brightness LEDs, adjustable light MONITOR

1. 10 inch IPS screen, 1280X720 resolution

2. PT rotating camera joystick

3. HD video recording system, the video resolution is 720P

4 Built-in character implantation system with USB Bluetooth keyboard

5. Built-in digital counter, the error rate is less than 1%

6. 3 video input interfaces

7. Manual recording microphone key

8. Audio, video output, with camera function

9. Built-in rechargeable 8800mA lithium battery pack, which can support continuous work for 8 hours Cable

1. Flexible coaxial cable 200m.

2. Cable diameter 7 mm.

3. Digital counter function, the error is less than 1%.

4. Cable length is optional from 100m to 200m (100m standard)

5. Dimensions: 480*340(H) (L)*250(W)mm

Additional information
